9 5/8" Zinc Alloy Spiral Vane Centralizer

Name: 9 58quot Zinc Alloy Spiral Vane Centralizer
Brand: Puyang Zhongshi Group
Price: 1 USD

Brand Name : Puyang Zhongshi Group

Model Number : 4 1/2"~20"

Certification : API,ISO,QHSE

Place of Origin : China

MOQ : 1

Price : Negotiable

Payment Terms : T/T, MoneyGram

Delivery Time : depends on quantity

Packaging Details : Wooden Box

Type : Solid Rigid

Material : Zinc alloy

Vane : Spiral type

Surface : Coated Powder or without

Vane number : 6

Production : Casting

Contact Now

9 5/8" Zinc Alloy Spiral Vane Centralizer

Spiral blade rigidity casing centralizer is made of spring steel which has been heat teated and hardened tempered to ensure proper and consistent spring characteristics

9 5/8" Zinc Alloy Spiral Vane Centralizer Features

Used in the less demanding vertical and intermediate wells.
Spiral blade to ensure proper and consistent spring characteristics
Wide vanes distribute load from the casing string into the well bore without gouging.
Provide excellent lead into restrictions and reduced drag.

9 5/8" Zinc Alloy Spiral Vane Centralizer Specification

Specification	casing size (mm)	Hole Size (mm)	Inner Diameter (mm)	Outer Diameter (mm)
4-1/2″×6″	114	152	118	146
5"×6 5/8"	127	168	131	162
5-1/2″×8-1/2″	140	216	142	210
7″×8 1/2″	178	216	182	210
7"× 9-1/2"	178	241	182	235
9-5/8″×12-1/4″	244	311	248	305
13-3/8″×17-1/2"	340	445	344	439

Product Tags:

Spiral Vane Bow Spring Centralizer

9 5/8" Bow Spring Centralizer

Zinc Alloy Spiral Vane Centralizer

9 5/8" Zinc Alloy Spiral Vane Centralizer Images
